To obtain good performance from electric transformers, the insulating oil should be free from moisture, dissolved gases and particles as contaminated oil loses its characteristics of dielectric strengths, resistivity and loss factor. Moisture favors acid and sludge formation. |
|
The oil treatment plants manufactured by have been designed specifically for the filtration, dehydration and degassing of the insulating oils used with transformers, electric cables, switch gears and turbines. |
|
We are Manufacturer, Supplier, Exporter of Oil Filtration Plants, Turbine Oil Filtration Plants, Transformer Oil Filtration Plants, Mobile Oil Filtration Plants, Transformer Oil Filtration Plants, Vacuum Impregnation Plants, Vacuum Drying Autoclave and our set up is situated in Pune, Maharashtra, India.
|
|
|
|
|
|
|
|
Oil Filtration Plant
|
Our filtration plants purify and upgrade transformer oil to comply with standard specifications. These plants can be designed as per customer’s specifications and are also available in varying capacities covering a whole range of applications in low, high and extra high voltage equipments. They perform the following functions: |
|
Removal of suspended impurities such as dust, rust, scales, colloidal carbon oxidation sludge etc. up to < 1 micron. |
|
Degassing and Dehydration of Transformer Oil with vacuum
Circulation of heated Oil and Filling of treated oil in Transformer tank
Prevention of acid formation by evaporation and adsorption method |
|
|
|
|
|
|
Turbine Oil Filtration Plant
|
We manufacture Oil filtration plants with varying capacities ranging from500 LPH to 10000 LPH. These plants are available as single stage and double stage variants depending upon the volume of insulating oil o be filtered. If higher capacity plants are required by the clients we can customize our plants to fulfill their requirements. The plants are also designed as mobile units besides the regular stationary unit. For outdoor usage they are supplied with and enclosure. The plant treats the unqualified turbine oil and removes the impurities from it to improve its quality. It efficiently removes water, gas and other impurities especially from emulsified turbine oil. |
|
Features:
-
Automatic systems with automatic advance system for safety, pressure, electricity and temperature constancy with infrared liquid-
-
Has a trapezoidal, spiral, automatic back flushing system.
-
Automatic Unmanned, On-line oil purification with turbine or water turbine
-
Breaks emulsification thoroughly with high- molecule polymeric material
-
Thoroughly clears the liquid water, free water and 80% dissolved water with effective dewatering with one and two step dehydration method
-
Distinctive technique removes impurities by filtering through double FH trapezoidal network and absorbing by high polymer material
-
Has the capacity to equal or surpass 200 and make the cleanness lower grade 6(NAS1638) with its advanced dielectric condensation devices.
|
|
This Vacuum Turbine Oil filter uses an advanced detaching theory of membrane which clears water and emulsification to purify the lubricant. The oil emulsifies to a much lesser degree after treatment. This TYA series prevent damage to the lubrication system and extends the life of both the insulating oil and the machinery. |
|
|
|
|
|
|
Transformer Oil Filtration Plant
|
Our oil filtration plants are used to remove impurities from transformer and switchgear oil such as moisture, dirt, air and other gases. This is a `low temperature and high vacuum` principle based equipment as per the International Standards 6034 (1989) and its latest revision. We manufacture plants of variable capacities of 600 to 10000 lph which can be customized to special capacities if required by the clients. This plant takes the impure oil into the system through the inlet ball valve and then pumps it through by a positive displacement pump. A filter prior to this removes solid particles up to 1mm size and magnetic particles. After heating the oil up to 60°c it passes through the cartridge filters, where particles up to 5 microns are filtered. A specially designed vacuum chamber removes moisture, air and all the gases with the help of vacuum. The oil falls by way of gravity over the media inside forming a thin film of oil, exposing a larger surface area. The dissolved moisture and gases are evacuated and the oil is ready. |
|
|
|
|
|
|
Mobile Oil Filtration Plant
|
During
its operation of generating, transmitting and distributing power
transformers give out heat which is absorbed by insulating oils. This
oil has a tendency to absorb moisture from windings which leads to
gradual deterioration of dielectric strength. Our filtration systems
provide economical and efficient methods of purifying this lubricant.
The unit consists of: |
|
-
Filter
Unit,
-
Indirect
system of Oil Heating,
-
Vacuum
Dehydration / degasification Unit
-
Condenser
and condensate receiver
-
Feed
and delivery pump
-
Piping
& Valves
-
Control
Panel
|
|
Components
of Plant |
The filter unit is a coarse strainer with a wire mesh filter element for retaining solid particles and a powerful magnet for retaining magnetic particles. It has round filter paper discs held under spring compression. Specially designed heaters with low watt density heat the auxiliary heating oil, which in turn heats the transformer oil maintaining a temperature of 70-80 C. The cylindrical external pressure vessel is fitted with various shallow drip trays and a specially designed spray pipe to increase surface area. The vapor from dehydration chamber is condensed in a condensate receiver of welded M. S. construction. There are feed and delivery pump of rotary gear type coupled directly with motors. Water Separator Collect the water produced. A centralized control panel has indicators for all electrical devices. |
-
Imported
thermostat
-
Thermometer
for measuring temperature
-
Pressure
& Vacuum gauges
-
Flow
control indicator
-
Electronic
Float Control
-
Electrical
instruments, voltometers and ammeters
-
Electrical
overloads and overload releases for safety of motors.
|
|
|
|
|
|
|
Vacuum Impregnation Plant
|
The
Vacuum Impregnation Plants can be designed as per clients’
requirements and is provided with the following specifications. |
|
IMPREGNATION
CYCLE |
|
It
is designed as per the schematic diagram attached and is used for
varnish impregnation to be carried out in following steps: |
-
Pre-heating
the jobs in either Impregnation Chamber or Oven.
-
Evacuation
of Impregnation Chamber (after putting the jobs) to make the voids
in the jobs clear and drying of jobs for specific time &
required temperature / vacuum.
-
Induction
of impregnant (Varnish) in the Impregnation Chamber from impregnant
Tank to submerge the jobs in it.
-
Pressurize
the Impregnation Chamber with dry air or nitrogen to fill the voids
with impregnant.
-
Return
the varnish to impregnant Tank.
-
Evacuate
the Impregnation Chamber and cure the jobs either in impregnation
Chamber or in Oven for specific time.
|
|
Impregnation
chamber specifications : |
- Working
Pressure: @ 4 kg/ cm2 & Vacuum: As per process requirement.
- Lid
Opening: Screw Davit type for quick opening & closing.
- Chamber
Dimensions: as per job Size and Quantity
- Added
provisions are Oil Heating / cooling Jacket, Quick Clamping bolts,
Stirrer, Neoprene Gaskets, Sight glass, Illuminating Lamp, Pressure
Safety Valve, Vacuum & Pressure gauge
|
|
|
|
|
|
|
Vacuum Drying Autoclave
|
Our
Vacuum Drying Autoclaves are designed and manufactured as per the
specifications provided by our clients. We have the capability to
manufacture high performance autoclaves which increase the efficiency
and performance of any plant. This equipment comprises a vacuum
autoclave in which a cylinder containing a piston is situated at one
end and can be closed at the end by a hollow piston containing a
condenser casing. The cylinder is evacuated through a port and the
piston is lowered to close the port immediately an injection valve is
opened to fill the cylinder with an impregnating substance. When the
injection valve is shut the piston slowly presses the impregnant out
through the neck of the condenser casing. The pressure is increased
till the ejection valve opens. A blast of gas cleans the cylinder to
remove any remaining impregnant. |
|
|
|
|
|
|
